HUNTER SE

HUNTER SE is the Ackermann front steering drive-by-wire chassis designed for the challenging road conditions and speed requirements of urban roads. It features an ultra-compact design with a cutting-edge speed of 4.8m/s, better climbing capability, and overcoming obstacles. Based on modular design and standard CAN interface, users can easily install and expand a series of autonomous system components to realize autonomous driving and commercial robot applications such as parcel delivery, unmanned logistics, unmanned meal delivery, scenic spot patrolling, etc.



Upgraded Power System for High-speed Driving

Inherited the simplified design and steel body of the HUNTER Series, the HUNTER SE, with an upgraded power system and in-wheel hub motor technology, can provide a high driving speed of up to 4.8m/s. Taking the advantage of front steering similar to motor vehicles, the HUNTER SE can precisely control the motion while minimizing the wear and tear of the tier, suitable for long-time challenging indoor and outdoor operations.



Modular Shock Absorption Systems Portable Replacement Battery

The HUNTER SE has a combination of modular shock absorption systems including a swing arm at the front wheel and independent suspension at the back wheel, which enables it to easily traverse bumpers on city roads and climb ramps in industrial parks. With the onboard battery management system and the quick-release battery replacement design, your robot can enjoy non-stop operation of achieving high efficiency in different commercial autonomous driving applications.



Applications

Designed for the challenging road conditions and speed requirements of the urban roads, the HUNTER SE is dedicated to the development and commercial implementation of robotics and autonomous driving applications, including autonomous parcel delivery, unmanned logistics, unmanned food delivery, unmanned patrolling, etc.



Expandable Load to Support Rapid Secondary Development

HUNTER SE can easily integrate third-party sensors, IMU, and more in need to quickly build the robotic applications through the CAN protocol, as well as easy to access power from HUNTER SE. Also, we provide rich open-source SDK and ROS_PACKAGE.





Dimensions (L x Wx H)820 x 640 x 310mmExternal Power Supply24V/15A
Height123mm

Power Drive

Rear wheel hub motor driven

Weight42kgMotor350W*2 (Brushless DC Motor)
Maximum Payload50kgOperating Temperature

-20°C~60°C

Maximum Speed17.8km/hCommunication InterfaceStandard CAN
Climbing Ability30°Protection LevelIP22
Minimum Turning Radius1.5mBattery24V/30A Lithium Battery
Obstacle Surmounting Capacity50mmChargerAC220V Independent Charger
Battery Running Time2~3hCharging Time3h
Running Mileage>30kmBraking Method2m
